Slag Removal Automated Coolant Filtration System For Grinding
Product Details:
| Place of Origin: | China |
| Brand Name: | Diang Tianke |
| Certification: | ISO9001 |
| Model Number: | DATK-MX003 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pis |
|---|---|
| Price: | Negotiable |
| Packaging Details: | WOODEN CASE |
| Delivery Time: | 7-15 workdays |
| Payment Terms: | LC, T/T, PayPal, Western Union, Small-amount payment, Money Gram |
| Supply Ability: | 1 |
|
Detail Information |
|||
| Equipment Size: | 1100*600*1200nn | Equipment Weight: | 150KG |
|---|---|---|---|
| Working Air Pressure: | 0.2-0.5Mpa | Maximum Flow: | 6000L/h |
| Color: | White | Equipment Power: | 120W |
| Filtering Accuracy: | 20 Microns | ||
| Highlight: | Slag Removal Automated,Automated Coolant Filtration System For Grinding,Automated Coolant Filtration System |
||
Product Description
Grinding Machine Filtration Equipment, Automatic Slag Removal, Efficient Filtration Of Fine Powder
The grinding fluid purification machine adopts intelligent three-stage separation technology to quickly remove small particles suspended in the grinding fluid, with a separation rate of over 95%. It has intelligent control, one click start function, simple operation, convenient maintenance, no consumables, and works for less than 1 kWh in less than 1 hour, which is energy-saving and environmentally friendly.
| Equipment parameters | |
| Equipment size | 1100*600*1200mm |
| Handling traffic | 6000L/h |
| Basket capacity | 14L |
| Filtration | 20 microns |
| working voltage | AC220V |
| Power | 120W |
| Operating temperature | 0-50℃ |
Product features
1. One click start function, simple operation, intelligent control, convenient maintenance, and no consumables;
2. Power on for one hour, using less than one kilowatt hour of electricity, energy-saving and environmentally friendly;
3. Intelligent three-stage separation, with a separation rate of over 95%;
4. The appearance design is compact and beautiful, with universal wheels installed for easy promotion in the workshop;
5. Improve the service life of grinding fluid and alleviate the environmental pressure of wastewater treatment;
6. Unique high-speed centrifugal separation function, which can achieve online purification without affecting normal production;
7. High precision particle filtration and purification, with a separation particle size of up to 20 microns;
8. Pure physical filtration does not change the composition of the grinding fluid.
